| 5.0寸半反半透显示屏 | 尺寸 | Size | 5.0 inch transflective screen |
| 分辨率 | Resolution | 800*480 | |
| 支持接口 | Interface Type | MIPI、RGB | |
| 显示区尺寸 | Display Area | 108(H)*64.8(V) | |
| LCD 外型尺寸 | LCD Dimensions | 112.2(H)*70.09(V) | |
| 像素间距 | Pixel Pitch | 0.135(H)*0.135(V)mm | |
| 显示色彩 | Color | 16.7M color by 8 bit R.G.B.signal input | |
| 反射率 | White Reflectance | 12.50% | |
| 透过率 | White Transmittance | 0.84% | |
| 工作温度 | Operating temperature | -20℃~+70℃ | |
| 储存温度 | Storage temperature | -30℃~+80℃ | |
| 是否支持定制 | Customisation | Yes |
